senf::INet4Network Class Reference
IPv4 network prefix. More...#include <senf/Socket/Protocols/INet/INet4Address.hh>
Detailed Description
IPv4 network prefix.This class represents an IPv4 network prefix in CIDR notation.
Definition at line 218 of file INet4Address.hh.
Public Member Functions |
|
| INet4Address const & | address () const |
| Get the networks address. |
|
| unsigned | prefix_len () const |
| Get the networks prefix length. |
|
| bool | boolean_test () const |
true, if INet4Network is non-empty |
|
| bool | operator== (INet4Network const &other) const |
| Compare to networks for equality. |
|
| bool | match (INet4Address const &addr) const |
true, if the network includes addr |
|
| bool | match (INet4Network const &net) const |
true, if the network includes net |
|
| INet4Address | host (boost::uint32_t number) |
| Return the host with the given number. |
|
| INet4Network | subnet (boost::uint32_t net, unsigned prefix_len) |
Return the given subnet of this. |
|
Related Functions |
|
| (Note that these are not member functions.) |
|
| std::ostream & | operator<< (std::ostream &os, INet4Network const &addr) |
| Output INet4Network instance as it's string representation. |
|
| std::istream & | operator>> (std::istream &is, INet4Network &addr) |
| Initialize INet4Address instance from a string representation. |
|
Structors and default members |
|
| INet4Network () | |
| Construct empty (0.0.0.0/0) network. |
|
| INet4Network (INet4Address const &address, unsigned prefix_len) | |
| Construct network from given address and prefix length. |
|
| INet4Network (std::string const &s) | |
| Construct network from CIDR notation. |
|
Constructor & Destructor Documentation
| senf::INet4Network:: | ||||
| INet4Network | () | |||
Construct empty (0.0.0.0/0) network.
Definition at line 103 of file INet4Address.cci.
| senf::INet4Network:: | ||||
| INet4Network | ( | INet4Address const & | address, | |
| unsigned | prefix_len | ) | ||
Construct network from given address and prefix length.
Definition at line 107 of file INet4Address.cci.
| senf::INet4Network:: | ||||
| INet4Network | ( | std::string const & | s | ) |
Construct network from CIDR notation.
Definition at line 129 of file INet4Address.cc.
Member Function Documentation
| senf::INet4Address const & senf::INet4Network:: | ||||
| address | () | |||
Get the networks address.
Definition at line 111 of file INet4Address.cci.
| bool senf::INet4Network:: | ||||
| boolean_test | () | |||
true, if INet4Network is non-empty
Definition at line 117 of file INet4Address.cci.
| senf::INet4Address senf::INet4Network:: | ||||
| host | ( | boost::uint32_t | number | ) |
Return the host with the given number.
Returns the host with the given number within the network. If the number is larger than the maximum host number in the network, it is truncated. So host(0) is the networks own address, host(1) customarily is the default router and host(-1) is the broadcast address.
Definition at line 141 of file INet4Address.cci.
| bool senf::INet4Network:: | ||||
| match | ( | INet4Network const & | net | ) |
true, if the network includes net
The is true, if net is sub-network (or the same as) this.
Definition at line 135 of file INet4Address.cci.
| bool senf::INet4Network:: | ||||
| match | ( | INet4Address const & | addr | ) |
true, if the network includes addr
Definition at line 129 of file INet4Address.cci.
| bool senf::INet4Network:: | ||||
| operator== | ( | INet4Network const & | other | ) |
Compare to networks for equality.
Definition at line 123 of file INet4Address.cci.
| unsigned senf::INet4Network:: | ||||
| prefix_len | () | |||
Get the networks prefix length.
Definition at line 84 of file INet4Address.cci.
| senf::INet4Network senf::INet4Network:: | ||||
| subnet | ( | boost::uint32_t | net, | |
| unsigned | prefix_len | ) | ||
Return the given subnet of this.
The returned INet4Network will be a subnet of this with the given network number. The network number is comprised by the bits above prefix_len:
INet4Network("192.168.0.0/16").subnet(111u,24u) == INet4Network("192.168.111.0/24") INet4Network("192.168.111.0/24").subnet(1u,28u) == INet4Network("192.168.111.16/28")
- Parameters:
-
[in] net network number [in] prefix_len length of subnet prefix
Definition at line 146 of file INet4Address.cci.
Friends And Related Function Documentation
| std::ostream & | ||||
| operator<< | ( | std::ostream & | os, | |
| INet4Network const & | addr | ) | ||
Output INet4Network instance as it's string representation.
| std::istream & | ||||
| operator>> | ( | std::istream & | is, | |
| INet4Network & | addr | ) | ||
Initialize INet4Address instance from a string representation.
sets std::ios::failbit on the stream if an error occurred
- See also:
- INet4Address from_string()
The documentation for this class was generated from the following files:
- Protocols/INet/INet4Address.hh
- Protocols/INet/INet4Address.cc
- Protocols/INet/INet4Address.cci
