senf::ppi::module::PassiveQueueingSocketSink< Writer > Class Template Reference
[Source/Sink Modules]
QueueingSocketSink. More...
#include <senf/PPI/QueueingSocketSink.hh>
Detailed Description
template<class Writer = ConnectedDgramWriter>
class senf::ppi::module::PassiveQueueingSocketSink< Writer >
QueueingSocketSink.
Definition at line 138 of file QueueingSocketSink.hh.
Public Types |
|
| typedef Writer::Handle | Handle |
| Handle type requested by writer. |
|
| typedef Writer::PacketType | PacketType |
Public Member Functions |
|
| PassiveQueueingSocketSink (Handle const &handle, QueueingAlgorithm::ptr qAlgorithm) | |
| Writer & | writer () |
| Access the Writer. |
|
| Handle & | handle () |
| Access handle. |
|
| void | handle (Handle const &handle) |
| Set handle. |
|
| QueueingAlgorithm & | qAlgorithm () |
| void | qAlgorithm (QueueingAlgorithm::ptr qAlgorithm) |
Public Attributes |
|
|
connector::PassiveInput < PacketType > |
input |
| Input connector from which data is received. |
|
| console::ScopedDirectory < PassiveQueueingSocketSink < Writer > > |
dir |
Member Typedef Documentation
| typedef Writer::Handle senf::ppi::module::PassiveQueueingSocketSink< Writer >:: | ||||
| Handle | ||||
Handle type requested by writer.
Definition at line 140 of file QueueingSocketSink.hh.
| typedef Writer::PacketType senf::ppi::module::PassiveQueueingSocketSink< Writer >:: | ||||
| PacketType | ||||
Definition at line 144 of file QueueingSocketSink.hh.
Constructor & Destructor Documentation
| senf::ppi::module::PassiveQueueingSocketSink< Writer >:: | ||||
| PassiveQueueingSocketSink | ( | Handle const & | handle, | |
| QueueingAlgorithm::ptr | qAlgorithm | ) | ||
Definition at line 60 of file QueueingSocketSink.ct.
Member Function Documentation
| void senf::ppi::module::PassiveQueueingSocketSink< Writer >:: | ||||
| handle | ( | Handle const & | handle | ) |
Set handle.
Assigning an empty or in-valid() handle will disable the module until a new valid handle is assigned.
Definition at line 81 of file QueueingSocketSink.ct.
| Writer::Handle & senf::ppi::module::PassiveQueueingSocketSink< Writer >:: | ||||
| handle | () | |||
Access handle.
Definition at line 53 of file QueueingSocketSink.cti.
| void senf::ppi::module::PassiveQueueingSocketSink< Writer >:: | ||||
| qAlgorithm | ( | QueueingAlgorithm::ptr | qAlgorithm | ) |
Definition at line 125 of file QueueingSocketSink.ct.
| senf::ppi::QueueingAlgorithm & senf::ppi::module::PassiveQueueingSocketSink< Writer >:: | ||||
| qAlgorithm | () | |||
Definition at line 59 of file QueueingSocketSink.cti.
| Writer & senf::ppi::module::PassiveQueueingSocketSink< Writer >:: | ||||
| writer | () | |||
Access the Writer.
Definition at line 47 of file QueueingSocketSink.cti.
Member Data Documentation
| console::ScopedDirectory<PassiveQueueingSocketSink<Writer> > senf::ppi::module::PassiveQueueingSocketSink< Writer >:: | ||||
| dir | ||||
Definition at line 147 of file QueueingSocketSink.hh.
| connector::PassiveInput<PacketType> senf::ppi::module::PassiveQueueingSocketSink< Writer >:: | ||||
| input | ||||
Input connector from which data is received.
Definition at line 146 of file QueueingSocketSink.hh.
The documentation for this class was generated from the following files:
